Plano-Convex Cylindrical Lenses
Still deciding? Get samples first, Contact US !
View similar products
Tag list
- Detailed
-
Plano convex cylindrical lenses are positive-power optical components featuring one flat (plano) surface and one convex cylindrical surface. They focus collimated light along the curved axis only, leaving the orthogonal axis completely unchanged—delivering precise one-dimensional beam control for laser shaping, line generation, and anamorphic correction.
Parameters
Specification
Material
Optical Glasses, Fused Silica, Sapphire, Infrared Material, etc.
Dimension Range
0.5 ~ 350mm
Dimension Tolerance +/-0.01mm Focal Length Tolerance +/-1% PV λ/10 Surface Quality 20-10 Centration ≤30‘’ Clear Aperture > 90% of diameter Bevel 0.2mm × 45° Coating As customer's request Key Features
- One-Dimensional Focusin： Shapes light into a sharp line rather than a point, enabling precise linear illumination and stable laser line generation.
- Positive Optical Powe：Efficiently converges incoming light, ideal for laser diode collimation and elliptical beam circularization.
- Aberration-Reduced Design：Engineered to suppress spherical aberration, delivering steady performance for high-precision imaging and metrology.
- Multi-Material Versatility：Offered in N-BK7, UV fused silica, CaF₂ and ZnSe, supporting applications across UV, visible and infrared spectra.
- Custom Coatings & Dimensions：We provide customized AR coatings, alongside standard and custom dimensions for smooth OEM integration.
- One-Dimensional Focusin： Shapes light into a sharp line rather than a point, enabling precise linear illumination and stable laser line generation.
