The micro prisms processing requires special capabilities and unique skills, we can reach the dimension of micro prism is less than 0.3mm, micro prisms occupy very little space inside an assembly or optical systems. These micro prisms are applied to the applications, such as life science, industrial endoscopes, optical fiber communication, etc.
Parameter Ranges
Material: Optical Glasses, Fused Silica, Infrared Material, etc.
Dimension Range: 0.3~5.0mm
Dimension Tolerance: +/-0.01 mm
PV : 1/10 Lambda
Surface Quality: 10-5
Angle Tolerance：+/-30’’
Coating: As customer's request
The Application of Micro Prisms
Micro prism is a common optical component that achieves deflection and separation of light through light refraction and reflection, which are key components for manufacturing large-scale optoelectronic systems. They have the advantages of small size, light weight, and low cost, JT's micro prisms are mainly used in optical communication, optical instruments, spectral analysis, and optical displays, also used in the field of medical equipment and life sciences, such as endoscopes or fiber bundle endoscopes and microscopic, biochip detection and analysis, retinal imaging, bioimaging and non invasive surgical treatment, as well as industrial, such as fiber optic coupling communication, laser beauty, laser processing, detection applications, etc.
JT Micro Prisms Advantages
• Precise angular deviation to meet customer's requirements
• Rapid prisms prototyping to mass production
• High reflectivity with metal and dielectric coatings
• Competitive price and experienced processing team
